Cobra Wireless GPR Yer Altı Görüntüleme
Yorum Yap/ Oku (0 Yorum)
1.473.960,00 TL
154.090,24 TL den başlayan taksitlerle!!
İÇERİK DETAYI:
A. Cobra WiFi GPR, Wireless 2 channel GPR-kit. Complete GPR-kit including Post Processing Software - 1 Kit
COBRA WiFi GPR kit. For technical specs: Enclosed brochure
Complete GPR Data Acquisition System including:
System Details
1. Integrated 2 channel GPR, with simultaneous display of both shallow and deep targets, WiFi operation
2. Cobra CBD Antennas: 3 Multi Frequency Antennas 200/400/800 MHz with operating band 50-1400 MHz
3. Integrated 73 Wh Li-Ion battery with 8 h operation
4. Data Acquisition Software DAQ, (Cobra DAQ)
5. Post Processing Prism 2 with 3D export module
6. USB with DAQ/Post Processing software/manual
7. External SW-encoder/connector, (10 mm resolution)
8. Cart with quick release wheels/ cart Push/Pull handle.
9. Rugged Terrain kit: Tow Sled for use in any terrain with protecting/exchangeable wearing Skid Pad
10. External Power/Charger, Ethernet RJ/45 connectors
11. External Mascot 2241 Battery Charger
12. Operating Manual on Cobra USB-disk
13.
1 day training in Boden, Sweden
B. Cobra DAQ SP4/ Rugged Tablet PC Control Unit: 1 Kit
- 6th generation Intel Core i5-6300U 2.4-3 GHz, 4GB DDR3, 128GB SSD, 12.3" TFT LCD HD (2736x1824). Sunlight readable IPS display with PROCAP multi-touch technology + digitizer pen (1024 pressure levels), Dual Band WiFi
- 802.11ac/802.11a/b/g/n, Bluetooth (v4.0), 8MP autofocus rear camera & 5 MP front camera, Windows 10 Pro (64-bit),
MIL-STD -810G drop-tested impact resistant non-slip composite material.
- RAM Tactical Cart Mount/ Adjustable double socket arm with 1.5” balls Tough Claw and quick release socket
C. Rugged Transport Case HPRC 4801 for Cobra WiFi GPR
COBRA CBD WIRELESS GPR
Introducing the smart CBD ANTENNA
Outstanding 50-1400 MHz bandwidth
Replaces several conventional antennas
FEATURES
WIRELESS OPERATION — No need for cables
PATENT PENDING CBD ANTENNAS
CBD ANTENNA TRANSMITS TRIPLE FREQUENCIES — 200, 400 and 800 MHz
ULTRA WIDE BAND PERFORMANCE —50 to 1400 MHz (1350 MHz bandwidth)
REPLACES SEVERAL CONVENTIONAL ANTENNAS
WITHOUT "DEAD ZONES” OR BLIND SPOTS
BLENDED FREQUENCY DATA — Optimal frequency automatically selected for all depths
UNIQUE RELATION FREQUENCY/VELOCITY —Proprietary formula
AIR COUPLED OPERATION — No need for ground coupling
COMPLETE GPR SYSTEM — 2 channel GPR, CBD-antennas, CU, Cart, Transport case
WIDE SELECTION OF CONTROL UNITS — Rugged PC with bundled software
SMART CART — Quick release wheels for push and pull operation
COMPACT AND FLEXIBLE SYSTEM — Only 15 kg
OPTIONAL REAL TIME SAMPLING
THE SMART GPR
The COBRA CBD WIRELESS GPR collects data from hundred thousands of pulse reflections each second to help researchers identify objects below ground.
It works in a
multi frequency band from 50 to 1400 MHz, thus replacing several antennas with different frequencies used by other and older GPR systems.
HOW IT WORKS
The unique CBD antenna transmits pulses with triple frequencies in a blended pulse form. The CBD antenna selects the optimal frequency needed for all layers and targets at different depths.
The CBD antenna data received can then be used for accurate velocity/RDP values for layers and targets via frequency analysis (using a proprietary formula - with
linear relation between reflected frequency and velocity).
3-D RADAR DEPTH SLICE, HORIZONTAL VIEW
A 3-D software translates several 2-D radar profiles into a 3-D map, depth slice, at different depths.
For full 3-D, the spacing between 2-D survey lines must be very close ( λ/4).
The depth slice below shows a buried Roman building wall remains, at Carnuntum, Austria.
Benefits:
GPR/Antenna system with rugged PC and cart
Multiple applications - 0-10 m depth range
Real-time working with 2x depth range and channel options
No additional survey needed
Best penetration and data quality in head-to-head tests
APPLICATIONS & USES (KULLANIM ALANLARI)
Geology and Mining
Locate gemstones pockets or find kimberlite, lateritic nickel, as well as cracks in bedrock and building stones. Map internal structures and voids in
soil .
Infrastructure & Utility Mapping
Inspect internal structures and identify voids, such as roads, bridges, tunnels, railways
and drains, and locate different types of material such as plastic, concrete, clay and metal pipes. Map concrete before drilling, cutting or coring. Detect obstacles in front of directional drilling operations.
Military and Security
Locate tunnels, bunkers, hidden weapons
and drugs. Find
land mines and unexploded ordnance (UXO).
Through wall imaging.
Rescue Operations
Locate trapped victims under collapsed buildings and landslides.
Environmental
Locate hazardous waste, UST-location. Delineation of contaminant plumes and product spills. Map shallow lakes and rivers.
Snow & Ice
Complete airborne mapping of snow and ice thickness, which allows for the findings of buried items. Find crevasses and avalanche victims.
Profile ice roads in detail. Glaciology research.
Agricultural and Forestry
Locate agricultural and golf-green drainage tiles. Determine soil water content and conductivity. Map tree roots and rot in wood.
Archaeology & Forensics
Pre-excavation mapping of buried structures, foundations, burials
and chambers.
WHY
MULTI FREQUENCY ANTENNAS?
The COBRA CBD Frequency Advantage
COBRA CBD GPR uses a patent pending unique triple frequency antenna design (200, 400 and 800 MHz nominal frequencies). Because the CBD-antennas emits three ultra
wide band pulses (150% of nominal frequencies compared to 100% for conventional antennas), that overlap and
blend together it can replace multiple antennas with nominal frequencies between 200 and 800 MHz. (See frequency spectrum below)
• Mixed/blended data with
automatic optimum frequency selected through all depths in one single file.
•
Near surface data with high resolution/frequency and deep targets with lower required frequencies.
• No need to set frequency filters. The smart CBD antenna filters by itself.
• No ”dead zones” or blind spots in data due to blended frequencies.
• Calculate velocity directly from frequency content with
proprietary formula.
•
Real Time Sampling technology option
•
Air coupled operation without ringing. (Other antennas must be ground coupled to avoid ringing)
COBRA CBD WIRELESS GPR – TECHNICAL SPECIFICATIONS:
ANTENNA / GPR: 2 channel Ground Penetrating Radar system with shielded antennas
Antenna type: CBD*
Multi Frequency Antenna (* Patent pending)
Nominal frequencies: 200/400/800 MHz
Operating bandwidth: 50-1400 MHz
Applied voltage: 200 V
Sample rate: 100,000 samples/second
Scan rate: 1-100 scans/s per channel @ 512 samples/scan
Sample output:
16 bit digital raw data
CONTROL UNIT / CU
Selectable PC/PDA, Rugged,
MIL-STD -81F/G, water- and dust resistant, IP-65 or IP-67 with bundled
data acquisition. DAQ-software for control, display, processing
and storage of GPR-data.
Data format: Standard Geophysical SEGY Data Format (.sgy)
Data channels: 1 or 2 with individual settings for depth, filter
and gain
Vertical filters: Off, Digital
Horizontal filters: Stacking, Background removal
Gain points: 1- 10 Linear gain
Gain levels: 0 to +60 dB
Data storage: Raw data storage with memory for Gain used
Data file size: Limited only by available HDD-space
SURVEY CART
Push and Pull non-metallic handle and support, tactical RAM-mount,
crade for recommended and purchased rugged PDA/PC. 12" quick release non-inflatable wheels.
High resolution SW-encoder.
ENVIRONMENTAL
Temperature: -20°C to 40°C internal temperature Humidity: 96% non-condensing Ingress protection: IP68 connectors
MECHANICAL
Size: (L x W x H) 60 x 52 x 29 cm
Weight: 15 kg
OPERATING
Operating platforms: Airborne operation,
high speed air-coupled operation, ground-coupled operation
Battery: Integrated 73 Wh Li-Ion
Operating time: 8 hours
Operating mode: Manual (1-100 scans/s), Distance (SW-encoder) with or without GPS
GPS positions: GPS positions integrated with GPR-data for every scan in both time- and distance mode
Operating depth: 0-2000 ns selectable. Typical 0-500 ns.
Depth Range: 0 - 10 m depending on ground properties.
ACCESSORIES
Hardware: Helicopter survey kit, Road/Railway kit, Transport case, High accuracy GPS, Harness
Software: GPR Data Aquisition software included (COBRA DAQ) for Cobra Wireless GPR and Cobra Plug-In GPR.
PRISM Post processing software with
3d export module (Voxler, Reflex 3d, GPRSlice).
